application :

the equipment mainly used in the ht heating treatment on carbon material, carbon nano, carbon fiber, negative electrode materials, graphite powder, contacting terminal material and such related material.

the furnace picture:


qq图片20170914093429

all our furnace can be custom made:

		nti-sml-4l	nti-sml-9l	nti-sml-57l
working size （l×w×h）	mm	150×250	200×300	350×600
heating type	/	induction heating
power control	/	igbt or silicon controlled
max.capacity	l	4	9	57
loading capacity	g	ht area capacity×product’s density(g/cm³)×1000 1l=1000cm³
input voltage	/	380v±10%，50hz/60hz 3 phase 5 wire
equipment structure	/	one power to one or two or four furnace
type	/	vertical
power	kw	80	100	150
frequency	hz	8000	8000	2500
max. temperature	℃	3200	3200	2800
working tem.	℃	3000	3000	2800
tem.uniformity	℃	±10	±10	±10
working environment	/	vacuum or ar、n₂atmospher environment (micro-positive pressure)

feature:

the furnace adopts alumina fiber products insulation, keeping temperature, domestically produced high-quality silicon molybdenum bar heating, high quality corundum tube furnace, the system can pre-pumped vacuum and gas using rotameter control, importing single loop intelligent temperature control instrument control, the equipment has the characteristics of uniform temperature, stable control, fast heating speed, energy saving, high working temperature, long service life and so on, it is an ideal equipment for scientific research.

vertical type
